Product Description
The NS-P124 Network Audio Amplifier is engineered for mid-scale networked audio systems that require higher output capacity and flexible system integration. Built around a high-speed dual-core processing architecture, it ensures consistent audio streaming and reliable SIP communication across enterprise-grade networks. As a Network Audio Amplifier, it serves as a central audio power unit in distributed PA infrastructures.
With a robust 240W output, the NS-P124 is capable of driving multiple speaker zones simultaneously, making it suitable for schools, commercial complexes, and manufacturing sites. This 240 watt amplifier supports both 100V constant-voltage systems and low-impedance speakers, offering system designers greater freedom when planning PA speaker amplifier layouts. Sound quality remains stable thanks to low distortion circuitry and precise tone adjustment.
The Network Audio Amplifier supports standard SIP protocol and a wide range of network communication standards, enabling seamless interaction with SIP servers, control software, and IP Paging Amplifier systems. Remote firmware upgrades and comprehensive protection features help reduce maintenance effort and ensure long-term operational reliability.
Key Features
● Mid-power Network Audio Amplifier for multi-zone paging systems
● 240 watt amplifier for medium-scale PA speaker amplifier projects
● Full SIP compatibility for SIP Paging Amplifier integration
● Stable network audio transmission with multiple protocol support
● Low distortion audio design with adjustable bass and treble
● Half-rack chassis optimized for equipment cabinet installation
Specifications
|
Model |
NS-P124 |
|
Rated Power at 8ohm |
2×120W |
|
Bridged Power at 100V |
240W |
|
Power Consumption |
325W |
|
Network Communication Protocol |
SIP, HTTP, HTTPS, IPv4, TLS, RTSP, RTP, RTCP, DHCP, DNS, NTP, TCP, UDP, IGMP, ICMP, ARP |
|
Network Interface |
10/100Base-TX,RJ45 |
|
Decoding |
OPUS, G722, G711U, G711A |
|
Input sensitivity / Impedance |
-0dBu/10kohm Unbalanced / Balanced |
|
Power Supply Voltage |
AC 100-120V, 50/60Hz or AC220-240V, 50/60Hz |
|
Speaker Output |
100V / 8Ω |
|
Frequency Response |
80Hz~17KHz (+1dB /-3dB) |
|
S/N Ratio |
>80dB (with A-Weight) |
|
T.H.D |
<1% (at rated power, 1kHz) |
|
Working Humidity |
90% |
|
Tone Controls |
Bass:100Hz(±10dB), Treble:10KHz(±10dB) |
|
Working Temperature |
0℃~+40℃ |
|
Product Dimension (W×H×D) |
215*44*330 mm (Half-Rack) |
|
Net Weight |
3.3kg |
Product Diagram
Products Application
The NS-P124 is designed for medium-sized facilities that require structured audio zoning and centralized management. Typical applications include school campuses, office buildings, shopping malls, and light industrial plants, where one Network Audio Amplifier can power multiple speaker lines while remaining fully manageable over the IP network.
In real-world projects, the NS-P124 is often installed in a central control cabinet and paired with paging consoles, PA management software, or SIP-based communication platforms. Acting as a reliable SIP Paging Amplifier, it supports routine announcements, bell schedules, background music, and emergency broadcasts across different zones, all driven by a single network infrastructure.
