Product Description
The NS-T20 sip paging gateway offers a streamlined solution for migrating analog audio systems to IP-based platforms with user-friendly operation. This efficient ip paging gateway features integrated volume control buttons and a single PoE network interface, providing straightforward setup and operation. The analog audio interfaces - including MIC input for dynamic microphones, speaker output for 15W passive speakers, and headset jack - allow direct connection to existing analog equipment such as ceiling speakers, horn speakers, and amplifier inputs. It is engineered for environments requiring simple yet reliable IP audio integration.
Equipped with advanced audio processing capabilities, this sip paging gateway supports multiple codecs including OPUS 48kHz and MP3 playback, ensuring superior sound quality through connected analog speakers. The front-panel volume controls enable immediate audio level adjustment without software configuration, making it particularly valuable in retail environments, small offices, and restaurants where quick adjustments are frequently needed. The GPIO alarm inputs automatically trigger emergency announcements through connected speaker systems when integrated with security devices.
Perfect for retail stores, hotels, and small to medium businesses, this sip paging gateway seamlessly connects traditional paging equipment to modern VoIP systems. The PoE capability reduces installation complexity while the compact metal enclosure ensures durability. By bridging analog speakers, microphones, and amplifiers with IP networks, the NS-T20 provides an cost-effective upgrade path to sophisticated SIP Paging System capabilities without replacing existing audio infrastructure.
Key Features
- Compact IP Paging Gateway with 15W built-in amplifier
- Compatible with SIP PBX server and VoIP systems
- Two-way communication via SIP Paging Adapter functions
- Interfaces: MIC, headset, speaker, GPIO alarm I/O, relay outputs
- Pre-recorded message playback (WAV/MP3) and RTP multicast
- Dual power supply: PoE or DC 12V with reset and volume control
Specifications
|
Networking |
|
|
Interface |
10/100 Base-TX, RJ45 |
|
Supported Protocols |
SIP, HTTP, HTTPS, IPv4, TLS, RTSP, RTP, RTCP, DHCP, DNS, NTP, TCP, UDP, IGMP, ICMP, ARP |
|
Security |
Password protection, IP address filtering, Digest authentication, User access log |
|
Audio |
|
|
Amplifier |
15W |
|
Decoding |
OPUS 48KHz, MP3 44.1KHz, G.722-ADPCM 16KHz, G.711-PCMU 8KHz, G.711-PCMA 8KHz, G726 8KHz, GSM 8KHz, LPCM-16bit-Stereo/Mono 44.1kHz |
|
VoIP |
|
|
Protocol |
SIP (compatible with VoIP, SIP devices such as IPPBX, IP Phone) |
|
Functions |
2 SIP Accounts SIP Direct IP Call, RTP Multicast |
|
Codecs |
OPUS,G722,G711U,G711A |
|
General |
|
|
Dimensions |
112 × 105 × 29 mm |
|
Power Supply |
PoE or DC 12V |
|
Interface |
1×MIC input, 1×Headset output, 1×Speaker output, 2×GPIO Alarm input, 1×GPIO Alarm output, 2×Relay Alarm output |
|
Enclosure Material |
Metal |
|
Weight |
250g |
|
Warranty |
2 years |
